UGA8000A General Description:

Ultra-Wideband Vector Signal Generation and Analysis System is composed of an arbitrary wave generator or a high speed digital oscilloscope and a microwave up and down converter. It is able to generate, calibrate, and analyze 8GHz of instantaneous bandwidth vector signal within the frequency cover rage of 12 ~ 67GHz.

Broadband Upconverter is used with arbitrary wave generator that adopts direct up-conversion technology to generate RF and microwave signal. It effectively avoided using the traditional broadband signal generating technology of I/Q modulator to prevent I / Q distortion deteriorates and complicated calibration work. Combining RFXpress signals with advanced RF / IF / IQ waveform generation and editing software, it is easy to generate various broadband vector signals for communications and radar.

The high-speed digital oscilloscope has excellent signal acquisition capability of up to 200GS / s. Supported by SignalVu vector signal analysis software, it can perform time correlation analysis and measurement in frequency domain, phase domain, amplitude domain and modulation domain to provide powerful ultra-wideband vector signal Analyzer function
